Rubber stop kickstart mechanism | Sachs

Woodruff key 3 x 3.7 mm

Total length: 9.15 mm · Material: Steel · Width: 3 mm · Height: 3.7 mm

Oil seal NBR 15/30/7 B AS | Sachs 503, 50/2

Width: 7 mm · Simmering type: B - With sheet metal outer casing / one sealing lip. · Manufacturer: Sachs · Ø inside: 15 mm · Ø outside: 30 mm · Material: NBR · Temperature resistance (min.): -30 - 100 °C · Pony spare part no.: A1830 · Sachs spare part no.: 0250 090 000

Cylinder roller Ø 4.5x6 Clutch | Sachs 50/2, 503 2AL/2BL (A1162)

Diameter: 4.5 mm · Width: 6 mm · Material: Steel · Surface: Hardened · Pony spare part no.: A1162 · Sachs spare part no.: 0232 107 000

Notched nail clutch lever Ø 3 x 20 mm Sachs 50/2, 50/3, 50/4, 503 AB/ABL/2AL/2BL (A1784)

Total length: 20 mm · Manufacturer: Sachs · Ø outside: 3 mm · Pony spare part no.: A1784 · Sachs spare part no.: 0249 023 000

GPO gasket set slot version | Sachs 50/3 3-speed engine

Manufacturer: GPO · Area of application: Standard · Hole spacing inlet: 31 mm · Ø outlet inside: 28 mm · Number of components: 8 pcs · Hole pattern [mm]: 51 x 40

Spacer washer 23/28/1 Gearbox | Sachs 50/3, 50/4

Ø inside: 23 mm · Nominal diameter: 23 mm · Ø outside: 28 mm · Material: Steel · Surface: blank / oiled · Thickness: 1 mm

Slotted nut M6 shift rod | Sachs 50/3, 50/4 foot control

Material: Steel · Surface: burnished · Nut type: Slotted nut · Thread type: M6x1 (standard thread) · Drive: Slot

Shift rod in gearbox | Sachs 50/4

Material: Steel · Surface: raw · Thread type: M5x0.8 (standard thread) · Thread type: M6x1 (standard thread) · Total length: 118.5 mm

Disk 15.7/27/3 | Sachs 50/3, 50/4 Kickstarter models

Ø inside: 15.7 mm · Nominal diameter: 16 mm · Ø outside: 27 mm · Material: Steel · Surface: blank / oiled · Thickness: 3 mm · Sachs spare part no.: A1598 · Sachs spare part no.: 0244 110 100

GPO piston 40.94 mm | Sachs 502, 50/2, 50/3, 50/4

Nominal diameter: 40 mm · Manufacturer: GPO · Ø outside piston (A): 40.94 mm · Ø piston pin (B): 12 mm · Compression height (C): 28 mm · Curvature (D): 3.2 mm · Total piston height (E): 49.4 mm · Number of piston rings (F): 2 pcs · Piston ring mold: Rectangular ring · Piston ring impact: Internal fuse (IS) · Piston ring height: 1.5 mm · Thick piston ring: 1.8 mm
