Manual | Sachs 50 - three-speed (50/3)

Gearbox cover gasket manual transmission | Sachs 50/2, 50/3, 50/4 A1827 0.4 mm (1A quality)

Material: Sealing paper · Number of components: 1 pcs · Color: sand-colored · Thickness: 0.4 mm · Total length: 215 mm · Width: 130 mm · Number of fixing points: 5 pcs · Pony spare part no.: A1827 · Sachs spare part no.: 0250 087 100

Repair instructions | Sachs 50 three-speed

Material: Paper · DIN format: A5 · Number of pages: 32 pcs

Shift rod in gearbox | Sachs 50/3

Material: Steel · Surface: raw · Thread type: M5x0.8 (standard thread) · Total length: 91.5 mm

swiing® revival locking plate drive wheel Inox | Sachs 50/2, 50/3, 50/4, 503 2AL/2BL (A1717)

Manufacturer: swiing® revival parts · Material: Chrome steel (stainless steel) · Thickness: 0.5 mm · Number of lobes: 1 pcs · Pony spare part no.: A1717 · Sachs spare part no.: A1717 · Sachs spare part no.: 0246 049 000

Repair instructions | Sachs 50 Zweigang (50/2)

Material: Paper · DIN format: A5 · Number of pages: 32 pcs

Repair instructions | Sachs 505/2

Material: Paper · DIN format: A4 · Number of pages: 62 pcs

Spare parts list | Sachs 50 three-speed engines

Material: Paper · DIN format: A5 · Number of pages: 40 pcs

Oil seal NBR 10/16/4.5 A Shift shaft | Sachs 50/3, 50/4

Temperature resistance (min.): -30 - 100 °C · Simmering type: A - With rubberized outer part / one sealing lip. · Manufacturer: Sachs · Material: NBR · Surface: rubberized · Place of use: Shift shaft · Ø inside: 10 mm · Ø outside: 16 mm · Width: 4.5 mm

swiing "must have" ignition adjustment guide

Manufacturer: swiing · Material: Paper · DIN format: A5 · Number of pages: 17 pcs

Shift key NOS | Sachs 50/3, 50/4

Manufacturer: Sachs · Material: Steel · Surface: Hardened · Thread type: M5x0.8 (standard thread)
