Brake caliper disc brake EBR Harry & hydraulic

EBR telescopic fork hydraulic silver | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: silver · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22.3 mm · Thread length: 58 mm · Ø outer head tube: 26 mm · Total length: 635 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 410 mm · Distance brake cam to wheel axle center-center: 35 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 28 mm

EBR telescopic fork aluminum (Harry) silver | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: silver · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22 mm · Thread length: 57 mm · Ø outer head tube: 26 mm · Total length: 705 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 458 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 30 mm

EBR telescopic fork hydraulic black | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: black · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22 mm · Thread length: 58 mm · Ø outer head tube: 25.9 mm · Total length: 635 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 410 mm · Distance brake cam to wheel axle center-center: 35 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 28 mm

EBR telescopic fork aluminum (Harry) black | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: black · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22.3 mm · Thread length: 58 mm · Ø outer head tube: 26 mm · Total length: 680 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 450 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 30 mm

EBR telescopic fork Harry aluminum black | Sachs

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: black · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22.1 mm · Thread length: 58 mm · Ø outer head tube: 26.1 mm · Total length: 705 mm · Head tube length: 220 mm · Fork bridge - center wheel axle: 435 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 30 mm

EBR telescopic fork hydraulic black EXTRA | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: black · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22 mm · Thread length: 60 mm · Ø outer head tube: 26 mm · Total length: 680 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 605 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 28 mm

Mounting plate disc brake EBR fork

Material: Aluminum · Number of fixing points: 4 pcs · Thickness: 6.5 mm · Ø mounting hole: 8.2 mm · Mounting type: Screws

EBR telescopic fork hydraulic extended black (with tabs for disc brake) | Puch

Manufacturer: EWC · Material: Aluminum · Color: Chrome · Material: Steel · Color: black · Surface: chrome-plated · Surface: varnished · Adjustable: Yes · Spar end distance (center-center): 150 mm · Ø head tube inside: 22.15 mm · Thread length: 58 mm · Ø outer head tube: 26 mm · Total length: 675 mm · Head tube length: 200 mm · Fork bridge - center wheel axle: 445 mm · Distance brake cam to wheel axle center-center: 35 mm · Thread type: MF26x1 (fine pitch thread) · Ø spars: 28 mm

Brake pads 61.5/28/7.3 Disc brake EBR Harry & hydraulic

Manufacturer: NewFren · Material: Composite materials · Material: Steel · Quantity: 2 pcs · Total length: 61.5 mm · Width: 28 mm · Thickness: 7.3 mm

Brake cable Ø 1.8 mm x 220 cm (pear-shaped nipple)

Ø nipple: 3.5 mm · Ø nipple: 6 mm · Manufacturer: Made in Germany · Material: Steel · Surface: blue galvanized · Number of components: 1 pcs · Area of application: Standard · Ø Stranded wire: 1.8 mm · Nipple shape: Pears · Cable length: 2200 mm · Nipple length: 10 mm

Inlet gasket 3 mm square | Puch

Thickness: 3 mm · Material: Sealing carton · Area of application: Standard · Reinforced: No · Place of use: Admission · Ø screw holder: 7.1 mm · Hole spacing inlet: 38 mm

Handlebar fringes Handle

Total length: 210 mm · Material: Imitation leather · Color: black

Brass nipple Ø 8 x 10 mm (Ø inside: 2 mm)

Ø nipple: 8 mm · Nipple length: 10 mm · Manufacturer: Made in Germany · Material: Brass · Ø Cable bushing: 2 mm · Nipple shape: Barrel (transverse)

swiing® ingenious brake shoes Ø 90 x 17 High End

Width: 17 mm · Manufacturer: swiing® ingenious parts · Number of springs: 1 pcs · Ø drum: 90 mm · Springs included: Yes · Color: red · Ø locating bolt: 10 mm · Slotted: No · Area of application: High End

Nostalgic Art tin sign "Puch Garage" green 20 x 30 cm

Manufacturer: Nostalgic Art · Material: Sheet metal (steel) · Width: 300 mm · Height: 200 mm · Ø mounting hole: 3.5 mm · Number of fixing points: 4 pcs

swiing brake shoes Ø 90 x 17 front High End | Sachs

Manufacturer: swiing · Ø drum: 90 mm · Width: 17 mm · Number of springs: 1 pcs · Springs included: Yes · Color: red · Area of application: High End

Toggle switch (ON-OFF) 12 mm with safety cap

Number of cables: 3 pcs · Color: red · Total length: 28 mm · Functions: Motor stop · Width: 16 mm · Number of positions: 2 pcs · Height: 52 mm · Ø mounting hole: 12 mm

Brake line 0.9 - 1.9 m (selection) black 28 / 90° incl. banjo bolts

Material: Rubber · Material: Steel · Thread type: MF10x1.25 (fine pitch thread) · Cable length: 900 mm · Cable length: 1000 mm · Cable length: 1150 mm · Cable length: 1400 mm · Cable length: 1600 mm · Cable length: 1700 mm · Cable length: 1900 mm · Mounting type: Screws · Color: black
